2-PC 150LB FLANGED VALVE

F-2B-150

2-PC 150LB FLANGED VALVE

NO PART NAME MATRIAL QTY
STAINILESS CARBON STEEL
1 BODY ASTM A351 Gr.CF8M/SS317 ASTM A216 WCB 1
2 CAP ASTM A351 Gr.CF8M/SS317 ASTM A216 WCB 1
3 BALL ASTM A351 Gr.CF8M/SS317 ASTM A351 CF8M 1
4 STEM ASTM A276 Gr.316/SS317 ASTM A276 Gr.304 1
5 SEAT PTFE+15GG/F PTFE+15GG/F 2
6 GASKET PTFE PTFE 1
7 THRUST WASHER PTFE PTFE 1
8 PACKING PTFE PTFE 1
9 GLAND ASTM A351 Gr.CF8 ASTM A351 Gr.CF8 1
10 STOPPER S.S.304 S.S.304 1
11 SNAP RING S.S.304 S.S.304 2
12 GLAND BOLT YASTM A193 Gr.B8 ASTM A193 Gr.B7 2
13 STUD BOLT ASTM A193 Gr.B8 ASTM A193 Gr.B7 4-8
14 SET NUT ASTM A194 Gr.8M ASTM A194 Gr.2H 4-8
15 HANDLE ASTM A536 Gr.65-45-12 ASTM A536 Gr.65-45-12 1
SIZE A B C D E F G H K M N S T
1 / 2" 15 107.9 42 M5XP0.8 25.2 35.0 1.6 60.4 88.9 15.7 4 11 11.1
3 / 4" 20 117.3 42 M5XP0.8 26.2 42.9 1.6 69.8 98.5 15.7 4 11 11.1
1" 25 127 50 M6XP1 32.2 50.8 1.6 79.2 107.9 15.7 4 14 11.1
11 / 4" 32 139.7 50 M6XP1 32.7 63.5 1.6 88.9 117.3 15.7 4 14 12.7
11 / 2" 38 166.1 70 M8XP1.25 42.2 73.1 1.6 98.6 127 15.7 4 17 14.2
2" 50 177.8 70 M8XP1.25 42.2 91.9 1.6 120.6 152.4 19 4 17 15.7
21 / 2" 65 190.5 70 M8XP1.25 42.2 104.6 1.6 139.7 177.8 19 4 17 17.5
3" 80 203.2 102 M10XP1.5 56.2 127 1.6 152.4 190.5 19 4 22 19
4" 100 228.6 102 M10XP1.5 56.2 157.2 1.6 190.5 228.6 19 8 22 22.3
5" 125 355.6 125 M12XP1.75 67.2 185.6 1.6 215.9 254 22.3 8 27 23.8
6" 150 393.7 125 M12XP1.75 67.2 215.9 1.6 241.3 279.4 22.3 8 27 25.4
8" 200 457.2 140 M16XP2 66.7 269.7 1.6 298.4 324.9 22.3 8 33 28.4
