CHECK VALVE 200PSI
Flanged check valve 10K 2"
CHECK VALVE 200PSI
| NO. | PART NAME | MATERLAL | Q'y | |
| 1 | BODY | CF8 | CF8M | 1 |
| 2 | DISC | CF8 | CF8M | 1 |
| 3 | LEVER | CF8 | CF8M | 1 |
| 4 | GASKET | 304 | 316 | 1 |
| 5 | NUT | 304 | 316 | 1 |
| 6 | COTTER PIN | 304 | 316 | 1 |
| 7 | GASKET | PTFE | 1 | |
| 8 | BONNET | CF8 | CF8M | 1 |
| 9 | BOLT | 304 | 4 | |
| 10 | HINGE PIN | 304 | 316 | 1 |
| 11 | THRUST WASHER | PTFE | 1 | |
| 12 | BOLT | 304 | 316 | 1 |
